Hydraulic valve manifolds for mobile applications How mobile applications work more precisely and efficiently
Our product range
We offer a comprehensive range of mobile hydraulic valves, including load-sensing, open centre and selector valves. Two product families are available in the load-sensing hydraulic valve range: the LX-6 series and the more compact LX-3 directional control valve. Both valve series can be customised.
We also offer several open centre directional control valves, including the RS 160, RS 210 and DX-6 models. For particularly cost-effective solutions, we also offer monoblock directional control valves.
For more information on our valves - whether load-sensing, open-centre or selector valves - please click on the links below.
Load-sensing directional valves
Our load-sensing directional valves work with upstream pressure compensators for systems with constant and variable displacement pumps. Up to ten functions can be controlled independently of each other - as long as the required flow rate does not exceed the max. pump flow. The directional valves were developed with a focus on high precision, fine control and energy efficiency. The flexible structure and the compact design makes the directional valves suitable for a wide range of applications.
Open centre directional valves
Our open-centre directional spool valves mainly work with fixed displacement pumps. The operating modes range from hand lever, bowden cable, hydraulic, pneumatic, electro-hydraulic or electronic controls. Piston position displays are optionally available. Moreover, there are optimised main control spools for various applications. The directional spool valves are developed with a focus on high precision, fine control and energy efficiency.
Selector valves
RV 713 is a 3 way selector valve designed for flows up to 42gpm (160 Lpm) and max. operating pressures up to 3,625 psi (250 bar). Spools, both 2 and 3 position, are available in various types including spools with built in check valves.
Standard spools are designed with under lap. A wide range of spool controls, both for manual operation as well as for remote control, are available.
Typical applications for RV 713 are tipping gears and demountable bodies. The configuration with check valve spools are typical used as a limit switch on trailers.
Smart lifting solutions - the new Tec SeriesAs testified to by PALFINGER
Complex challenges at inner-city job sites and lifting tasks that require long reaches continuously present PALFINGER customers with challenges. To meet these requirements, PALFINGER has completely redesigned its core product, the loader crane, ushering in a new era of crane models. It effectively combines the advantages of its predecessors with intelligent technologies, such as the innovative PALTRONIC 180 control system and the ultimate LX-6 load-sensing control valve manifold.
